SSB Crystal Filters

The following SSB crystal filters are representative of Network Sciences sideband filter capability. These filters feature excellent carrier rejection, stability and insertion loss.

Please refer to the Case Code description page for detailed case size and connector information.


CF (Fo)

NS-PN

3dB

Bandwidth

Insertion

Loss

Ultimate

Attenuation

Case

Code

1.6485 MHz

20127

2.4 kHz

4dB

>80 dB

D

1.6515 MHz

20128

2.4 kHz

4dB

>80dB

D

2.62 MHz

20213

2.1 kHz

5dB

>90dB

D

5.6936 MHz

20239

2.0 kHz

4dB

>80dB

G

5.6964 MHz

20240

2.0 kHz

4dB

>70dB

G

6.2985 MHz

20124

2.4 kHz

3dB

>80dB

O

8.9985 MHz

20129

2.4 kHz

4dB

>80dB

G

9.0015 MHz

20061

2.4 kHz

3dB

>80dB

G

9.0031 MHz

20047

2.7 kHz

4dB

>80dB

G

102385 MHz

20252

2.4 kHz

4dB

>70dB

G

10.2415 MHz

20253

2.4 kHz

4dB

>70dB

G

10.700 MHz

20088

2.1 kHz

5dB

>70dB

I

10.700 MHz

20228

2.2 kHz

5dB

>70dB

G

12.6983 MHz

20044

2.5 kHz

5dB

>70dB

I

12.7018 MHz

20045

2.5 kHz

5dB

>70dB

I

15.9986 MHz

20038

2.0 kHz

5dB

>70dB

I

16.0014 MHz

20039

2.0 kHz

5dB

>70dB

I

21.3984 MHz

20255

2.7 kHz

6dB

>70dB

I

21.4016 MHz

20256

2.7 kHz

6db

>70dB

I

Please contact Network Sciences if one of the below P/N's does not satisfy your requirement. We would appreciate the opportunity to help you solve your filter requirement
