Model |
Nominal Frequency MHz |
Passband Min. |
Stopband Max |
Attenuation Min |
Ripple Max |
Loss Max |
Termination Impedance |
|||
|
dB |
kHz |
dB |
kHz |
dB |
kHz |
dB |
dB |
(W//pF) |
||
|
214S7.5 |
21.4 |
3 |
±3.75 |
20 |
±18.0 |
70 |
-910 |
1.0 |
2.0 |
850//6.0 |
|
214S15 |
21.4 |
3 |
±7.5 |
18 |
±25.0 |
70 |
-910 |
1.0 |
2.0 |
1500//1.5 |
|
214S20 |
21.4 |
3 |
±10.0 |
10 |
±30.0 |
70 |
-910 |
1.0 |
2.0 |
1800//1.0 |
|
214S30 |
21.4 |
3 |
±15.0 |
15 |
±45.0 |
70 |
-910 |
1.0 |
2.0 |
2000//1.5 |
|
217S7.5 |
21.7 |
3 |
±3.75 |
15 |
±12.5 |
70 |
-910 |
1.0 |
2.0 |
1200//5.0 |
|
217S15 |
21.7 |
3 |
±7.35 |
15 |
±25.0 |
70 |
-910 |
1.0 |
2.0 |
1500//1.0 |
|
29S20 |
29.25 |
3 |
±10.0 |
10 |
±25.0 |
70 |
-910 |
1.0 |
2.0 |
1800//1.5 |
|
45S7.5 |
45 |
3 |
±3.75 |
20 |
±25.0 |
70 |
-910 |
1.0 |
2.0 |
650//3.5 |
|
45S12 |
45.0 |
3 |
±6.0 |
15 |
±20.0 |
70 |
-910 |
1.0 |
2.0 |
650//5.0 |
|
45S15 |
45.0 |
3 |
±7.5 |
15 |
±25.0 |
70 |
-910 |
1.0 |
2.0 |
650//3.5 |
|
45S30 |
45.0 |
3 |
±15.0 |
15 |
±60.0 |
70 |
-910 |
1.0 |
2.0 |
1200//3.0 |
|
77S15 |
77.55 |
3 |
±7.5 |
18 |
±28.0 |
50 |
-910 |
1.0 |
3.0 |
1500//1.0 |
|
109S24 |
109.65 |
3 |
±12.0 |
18 |
±60.0 |
65 |
-910 |
1.0 |
3.0 |
1500//1.2 |
