STANDARD 70 MHz VHF CRYSTAL AND LC BANDPASS FILTERS

Network Sciences offers complete capability for the design and production of 70 MHz filters with pass-bands from 2.4 kHz to 40 MHz.  We offer all filter design polynomials, including general synthesis for unique applications.


Note:  BW = Bandwidth;   SF = Shape Factor:    IL = Insertion Loss


NS P/N

BW (kHz) (min)

SF  ( dB/dB)

IL (dB) (max)

Ripple (dB) (max)

Delay (µsec)

(max)

Enclosure (in)

Connectors

20681

9

10:1 (60:3)

6

1

N/A

1.50x0.75x0.50

.030” pcb p-o

20861

10

5:1( 50/1)

4

1

N/A

0.93x0.51x0.50

.030" pcb-p-o

20823

10

3.5:1 (60/3)

7

1

N/A

2.38x1.02x0.50

.040" pcb p-o

20707

10

2.5:1 (35/1)

5

< 1

N/A

1.50x0.75x0.50

.030" pcb p-o

I202B

14

8.6:1 (30/3)

4

1

18

1.64x1.04x0.50

.030" pcb p-o

F112B

17

7.1:1

4

1

@CF:27+1/-2

1.64x1.04x0.50

.030” pcb p-o

20499

20

10:1 (70/3)

5

1

N/A

1.50x0.50x0.50

.030" pcb p-o

20845

20

5.0:1 (55/3)

4

1

N/A

1.175x0.675x0.23

.030" SM

20766

20

2.1:1 (40/3)

6

1

0.5 80% bw

2.18x0.75x0.50

SMA-F pcb stud

20809

38

2.25:1 (30/3)

4

1

N/A

2.0x0.62x.65

.030" pcb p-o

20812

50

4.0:1(60/3)

6

1

3.5 80% bw

2.00x0.60x.29

.030 SM

G6612

57

6.2:1 (60/3

10

1

4+/-20Khz

2.00x1.00x0.75

.030" pcb p-o

20810

70

2.3:1 (30/3)

4.5

2

N/A

2.0x0.62x.65

.030" pcb p-o

20813

75

2.6:1 (60/1.5)

6

1

2.5 85 % bw

2.30x0.60x0.50

.030" SM

20340

88

4.55:1 (40/3)

6

1

N/A

2.40x0.60x0.35

SMD

20777

90

1.45:1 (20/3)

5

1

N/A

1.04x0.45x0.46

.030" pcb p-o

20911

120

1.7:1 (40/3)

6

1

N/A

2.38x1.02 x0.50

BNC+ pcb p-o

20869

140

2.8:1 60/1.5)

5

1

5 90% bw

2.30x0.60x.050

SMA-F SM

20763

200

3.15:1 20/3)

3

1

N/A

1.00x0.50x0.50

.030" pcb p-o

20079

256

3.15:1 (40/1)

8

1

20 100% bw

1.50x0.60x0.50

.030" pcb p-o

20126

256

3.0:1 (40/1)

8

1

20 100% bw

1.20x1.03x0.75

.030" pcb p-o

20322

1000

4:1 (70/1)

16 ±1.5

1

N/A

3.15x1.5x0.50

SMA-F + inserts

10473

1000

6:1 (30/3)

8

1

N/A

2.38x1.00x075

.040" pcb p-o

C881E

2000

8.5:1 (60/3)

9

<1

 .02 80%,.03 100%

1.75x0.60x0.44

.030" pcb p-o

10017

5000

8.0:1(60/3)

4

1

N/A

2.20x0.75x0.75

SMA-F pcb stud

D881E

5000

6.0:1 (60/3)

4.5

<1

.01 80%,.015 100%

1.75x0.60x0.44

.030" pcb p-o

E881E

10000

6.0:1 (60/3)

2.75

<1

.007 80%,.015 100%

1.75x0.60x0.44

.030" pcb p-o

F881E

20000

5.5:1 (60/3)

2

<1

.005 80%,.0075 100%

1.75x0.60x0.44

.030" pcb p-o

G881E

40000

4:1: (60/3)

2

<1

.0032 80%,..00325 100%

1.75x0.60x0.44

.030" pcb p-o
