NETWORK SCIENCES 21.4 MHz BANDPASS FILTER SERIES


Network Sciences offers a complete line of 21.4 MHz filters. These filters offer a compact, robust, & cost Effective solution for your 21.4 MHz Bandpass application. This series of filters feature 3 dB bandwidths from 2 KHz to 12 MHz, offering low insertion loss and excellent selectivity. Some of the common standard filter specifications are highlighted below.



3 dB passband ripple …………………….……

60 dB / 3 dB Shape Factor  ………….……….

Group delay …………………………….….…..

Return loss ………………………………….….

Source & Load Impedance ……………………

Operating Temperature ……………………….

Enclosure ………………………………….…...

1 dB max. @ 25 ± 15° C, 2 dB max. Over operating temperature.

3.0 / 1.0 max

(See BPF analysis link for typical values)

(See BPF analysis link for typical values)

50 ohm  ± 5.0%

40° C to +80° C (Insertion loss below may increase 1 dB max.)

NS 18-10373 leaded case


Note: Network Sciences can offer any 3 dB bandwidth from 2 KHz to 12 MHz.
Contact the factory for your special bandwidth requirement



Note: The below links are .pdf files

NS   P/N

3 dB Bandwidth

(Min.)    (MHz)

 Insertion

Loss   (Max.)

BPF Analysis
Link

BPF Case
Link

10373-0.5

0.5

9

10373-0.5

18-10373

10373-1

1.0

6

10373-1

18-10373

10373-2

2.0

3

10373-2

18-10373

10373-2.5

2.5

3

10373-2.5

18-10373

10373-3

3

3

10373-3

18-10373

10373-4

4.0

3

10373-4

18-10373

10373-5

5.0

3

10373-5

18-10373

10373-6

6.0

3

10373-6

18-10373

10373-8

8.0

3

10373-8

18-10373

10373-10

10.0

3

10373-10

18-10373

10373-12

12.0

3

10373-12

18-10373
